Network meta-analysis was the first such technique to allow for the possibility that the indirect information might be biased, and to assess the degree of agreement between direct and indirect comparisons from the data.
The example presented in the original paper has some typographical errors. This page shows a worked example of a network meta-analysis, from a paper on treatments for glaucoma, by van der Valk and others.
The data are in comma-separated text format. The file analysis.R does the complete analysis. The file glaucoma.rda has preprocessed data in a suitable form for fitting the linear mixed models, with a predictor for each drug, coded +/-1 for the two drugs in a pairwise comparison and zero for drugs not involved. The data have also been reweighted, with variances multiplied by 2 for comparisons within a three-armed trial (since each person appears twice and would otherwise be double-counted).
The models can be fitted with the following code
library(nlme)
load("glaucoma.rda")
trough.lme<-lme(mu ~ 0 + betaxolol + bimatoprost + brimonidine + brinzolamide +
dorzolamide + latanoprost + placebo + travoprost,
~1|trtpair,data=troughdata,
weights=varConstPower(form=~sigma, fixed=list(power=1)))
peak.lme<-lme(mu ~ 0 + betaxolol + bimatoprost + brimonidine + brinzolamide +
dorzolamide + latanoprost + placebo + travoprost,
~1|trtpair,data=peakdata,
weights=varConstPower(form=~sigma, fixed=list(power=1)))
The output from the models is below. The treatment comparisons are the
fixed effect estimates. The incoherence is the intercept random effect
standard deviation (effectively zero in these data).
> summary(peak.lme)
Linear mixed-effects model fit by REML
Data: peakdata
AIC BIC logLik
-77.98308 -63.32883 49.99154
Random effects:
Formula: ~1 | trtpair
(Intercept) Residual
StdDev: 1.747687e-06 0.05480966
Variance function:
Structure: Constant plus power of variance covariate
Formula: ~sigma
Parameter estimates:
const power
0.4123657 1.0000000
Fixed effects: attr(peakdata, "formula")
Value Std.Error DF t-value p-value
betaxolol 0.06763815 0.01331770 9 5.078817 0.0007
bimatoprost -0.08429832 0.01408424 9 -5.985294 0.0002
brimonidine -0.01490472 0.01741234 9 -0.855986 0.4142
brinzolamide 0.08437913 0.02505425 9 3.367856 0.0083
dorzolamide 0.04280303 0.01409322 9 3.037135 0.0141
latanoprost -0.06449534 0.01089720 9 -5.918524 0.0002
placebo 0.18447008 0.01791467 9 10.297150 0.0000
travoprost -0.05928840 0.01363291 9 -4.348918 0.0019
Correlation:
betxll bmtprs brmndn brnzlm drzlmd ltnprs placeb
bimatoprost 0.071
brimonidine 0.028 0.172
brinzolamide 0.153 0.179 0.062
dorzolamide 0.323 0.220 0.086 0.473
latanoprost 0.088 0.549 0.314 0.199 0.273
placebo 0.173 0.328 0.107 0.507 0.534 0.341
travoprost 0.044 0.449 0.131 0.105 0.136 0.417 0.187
Standardized Within-Group Residuals:
Min Q1 Med Q3 Max
-2.06964198 -0.43427485 -0.03559876 0.66911129 2.07421950
Number of Observations: 36
Number of Groups: 17
> summary(trough.lme)
Linear mixed-effects model fit by REML
Data: troughdata
AIC BIC logLik
-81.00163 -67.16256 51.50081
Random effects:
Formula: ~1 | trtpair
(Intercept) Residual
StdDev: 1.626263e-08 0.1495982
Variance function:
Structure: Constant plus power of variance covariate
Formula: ~sigma
Parameter estimates:
const power
3.641353e-10 1.000000e+00
Fixed effects: attr(troughdata, "formula")
Value Std.Error DF t-value p-value
betaxolol 0.05430220 0.010817085 9 5.020040 0.0007
bimatoprost -0.06170327 0.011152761 9 -5.532556 0.0004
brimonidine 0.07376523 0.015080105 9 4.891559 0.0009
brinzolamide 0.05888197 0.016221087 9 3.629964 0.0055
dorzolamide 0.05503531 0.010456848 9 5.263088 0.0005
latanoprost -0.02632711 0.009074042 9 -2.901365 0.0176
placebo 0.14977410 0.012245448 9 12.231002 0.0000
travoprost -0.02748992 0.011463645 9 -2.398009 0.0400
Correlation:
betxll bmtprs brmndn brnzlm drzlmd ltnprs placeb
bimatoprost 0.088
brimonidine 0.016 0.093
brinzolamide 0.168 0.258 0.043
dorzolamide 0.305 0.290 0.053 0.550
latanoprost 0.091 0.522 0.178 0.242 0.297
placebo 0.184 0.436 0.069 0.572 0.604 0.388
travoprost 0.041 0.324 0.067 0.114 0.135 0.376 0.187
Standardized Within-Group Residuals:
Min Q1 Med Q3 Max
-2.0618580 -0.5756033 -0.1307495 0.4804651 1.9255973
Number of Observations: 34
Number of Groups: 17
The file analysis.R gives tider summaries
corresponding to Table 1 in the paper
> nice.summary(peak.lme)
peak.lme
Random effects:
Formula: ~1 | trtpair
(Intercept) Residual
StdDev: 1.747687e-06 0.05480966
Variance function:
Structure: Constant plus power of variance covariate
Formula: ~sigma
Parameter estimates:
const power
0.4123657 1.0000000
diff low up pvalue
betaxolol 0.07 0.04 0.09 0.000
bimatoprost -0.08 -0.11 -0.06 0.000
brimonidine -0.01 -0.05 0.02 0.392
brinzolamide 0.08 0.04 0.13 0.001
dorzolamide 0.04 0.02 0.07 0.002
latanoprost -0.06 -0.09 -0.04 0.000
placebo 0.18 0.15 0.22 0.000
travoprost -0.06 -0.09 -0.03 0.000
> nice.summary(trough.lme)
trough.lme
Random effects:
Formula: ~1 | trtpair
(Intercept) Residual
StdDev: 1.626263e-08 0.1495982
Variance function:
Structure: Constant plus power of variance covariate
Formula: ~sigma
Parameter estimates:
const power
3.641353e-10 1.000000e+00
diff low up pvalue
betaxolol 0.05 0.03 0.08 0.000
bimatoprost -0.06 -0.08 -0.04 0.000
brimonidine 0.07 0.04 0.10 0.000
brinzolamide 0.06 0.03 0.09 0.000
dorzolamide 0.06 0.03 0.08 0.000
latanoprost -0.03 -0.04 -0.01 0.004
placebo 0.15 0.13 0.17 0.000
travoprost -0.03 -0.05 -0.01 0.016
and
forestplots (which the journal didn't want)
