Kitfox Model IV Specifications
| Manufacturer: |
Skystar |
|
| Model: |
Kitfox Classic
4 |
| Year: |
1993 |
| Tail #: |
N328ML |
| Serial #: |
DCU033 |
| Top Speed: |
125 MPH |
| Range: |
300 Miles |
| MGTOW: |
1200 lbf |
| Dry Weight: |
769 lbf |
| Wingspan: |
32' |
| Wing Area: |
130.5 sq ft |
| AR: |
7.85 |
| VStall
(wheels): |
TBD
(~40 MPH) |
| VStall
(floats): |
~51
MPH |
| Fuel Capacity: |
26
gallons |
| Fuel burn (floats): |
5.2
gallons/hour @ 5600 RPM |
| Cruise velocity: |
75
MPH (IAS) |
| Powerplant: |
Rotax
582-LC (65 Hp with C-Transmission) |
| Propeller: |
Ivoprop
in-flight electrical adjustable pitch (#UL366E) |
| Floats: |
Full
Lotus inflatable floats (FLF-14-G) |
| Vx
(max dy/dx) |
56
MPH @1089 lbf |
| Vy
(max dy/dt) |
63
MPH @ 1098 lbf |
| Service Ceiling: |
14,000' |
| Max rate of
climb: |
600
ft/min |
| MAC: |
51.1" |
|
|
