Sunlight- and ozone-driven abiotic generation of organohalogens at the sea-air interface:
Sunlight- and ozone-driven abiotic generation of organohalogens at the sea-air interface:
Researchers
have long theorized that solar irradiation of seawater
generates low, steady-state levels of reactive halogen
species, or RHS (e.g., Br•,
ClBr•-, Br2•-,
Br2, and HOBr) at the
ocean surface. This is expected to occur primarily
through the reactions of bromide with hydroxyl radical
(HO•), which may be
generated by various processes at steady-state
concentrations ranging from 10-18
to 10-17 mol/L. Some
studies also suggest that RHS may be formed through
interactions of photoexcited triplet-state dissolved
organic matter, 3DOM*,
with bromide. Furthermore, absorptive uptake of
ambient ozone (O3) at the
ocean surface has recently been identified as a
possible source of iodine-containing RHS (e.g., HOI).
A number of RHS (e.g., Br2, HOBr, HOI) are known to be
capable of brominating or iodinating dissolved organic
matter (DOM), and could in turn represent an
important, but relatively unexplored abiotic source of
organohalogens at the ocean surface, which could have
important implications for a variety of atmospheric
processes (e.g., tropospheric and stratospheric O3 depletion, cloud formation,
mercury deposition). In the interest of characterizing
the potential contributions of sunlight- and O3-driven RHS production to
organohalogen formation, we have developed
complementary analytical protocols to assess: (a)
non-specific halogenation of bulk DOM, and (b)
specific halogenation of a well-defined probe
compound, during exposure of seawaters to natural
levels of sunlight and/or ozone.
In protocol (a), non-specific DOM bromination and iodination are quantified by ICP-MS analysis of bulk organohalogen concentrations in DOM extracts after sequential solid phase extraction and halide-selective ion exchange. In protocol (b), a non-volatile, UVA-transparent heterocyclic nitrogen compound which yields a single brominated or iodinated product upon reaction with non-radical brominating or iodinating species (i.e., X2, HOX) is utilized as a selective probe for the detection of RHS. Halogenated product yields in seawater samples are then quantified using LC-MS/MS with multiple reaction monitoring. Through the combination of these approaches, we are quantifying the formation of low (typically nanomolar) levels of bulk organobromine and organoiodine in seawater during exposure to solar radiation or ozone, in order to evaluate the significance of photochemical or ozone-driven halogenation of dissolved organic matter as an abiotic source of organohalogens at the ocean surface. Our work focuses in particular on the role of such processes in estuarine seawaters, which are enriched in photoreactive terrestrial DOM originating from riverine plumes.
Research
Aqueous
free available chlorine (typically comprising Cl2, HOCl, and OCl-) remains widely utilized as a
disinfectant in water treatment on account of its low
cost, ease of use, and generally high efficacy.
However, certain microbial agents (e.g., bacterial
endospores, Cryptosporidium
parvum oocysts, Giardia
lamblia cysts, Mycobacterium
avium cells) exhibit high levels of
chlorine-resistance, often necessitating the use of
capital- and energy-intensive alternative approaches
to disinfection (e.g., UV irradiation, ozonation) to
ensure acceptable water quality. In recent
investigations, we have found that the effectiveness
of chlorine-based disinfection processes toward such
microorganisms can be markedly enhanced simply by
utilizing sunlight to generate the potent oxidants
hydroxyl radical (•OH) and
ozone (O3) in situ
through the photolysis of free chlorine.
For example, the chlorine
exposure, or CT (in mg
Cl2 L-1
min), required for 99% inactivation of highly
chlorine-resistant Bacillus
subtilis endospores (common surrogates for
chlorine-resistant pathogens) can be lowered by
two-thirds during simulated solar photolysis of
chlorine at pH 8 and 10° C, as a result of co-exposure
of spores to O3 and •OH. We have also found that C. parvum oocysts can be
inactivated by >99% under similar conditions, even
though no oocyst inactivation is achievable in the
absence of light.
Our ongoing research on this topic focuses on elucidating the mechanisms responsible for inactivation of microorganisms (particularly with respect to synergism amongst multiple disinfectants), investigating the potential for inactivation of other chlorine-resistant pathogens such as M. avium and Coxsackievirus B5, and quantifying impacts of chlorine photolysis on the formation of regulated inorganic and organic disinfection by-products (e.g., chlorite, bromate, trihalomethanes, and haloacetic acids). One of our primary objectives in this investigation is development of a framework for accurately predicting the inactivation of chlorine-resistant microorganisms during sunlight-driven chlorine photolysis, with the ultimate aim of facilitating practical implementation of this approach for use in small municipal water systems and decentralized, point-of-use treatment applications (e.g., as a means of boosting the efficacy of solar disinfection, or SODIS).
Photochemical activation of free chlorine for enhanced inactivation of chlorine-resistant waterborne pathogens during drinking water disinfection:
Free
available chlorine is most commonly produced through
the electrolysis of HCl or NaCl solutions to generate
Cl2(g) or NaOCl. However,
energy consumption associated with the electrolytic
production of chlorine is extremely high,
necessitating either dedicated electrical supplies at
larger scales, or battery-powered electrochemical
cells for smaller scale, decentralized applications.
In the interest of lowering the energy footprint and
accessibility of chlorine production, we are
investigating a potential alternative means for
generating chlorine independent of electrical input
and with very limited physical infrastructure. Certain
classes of natural and/or synthetic organic
photosensitizers (e.g., aromatic ketones) can be
utilized to produce Cl2(g)
directly via sunlight-mediated oxidation of aqueous
HCl or of acidified brines containing high
concentrations of Cl-
(e.g., seawater or NaCl solutions). The resulting Cl2(g) can be sparged with a
continuous stream of external gas into a “trap” vessel
containing an alkaline solution (to generate a NaOCl
stock) or a raw drinking water (to provide direct
disinfection), as depicted in the accompanying figure.
We are characterizing and optimizing the photosensitized oxidation of Cl- to Cl2 by such sensitizer compounds through the use of simulated and natural sunlight. The near-term objective of this investigation is the development of a portable, energy-efficient means of generating aqueous free chlorine that may subsequently be used alone or in combination with other processes for the inactivation of pathogenic microorganisms in compromised drinking water sources – without the need for an external electrical power supply. The broader objectives of the investigation are to: 1) expand opportunities for point-of-use drinking water disinfection through on-site generation of chlorine, 2) adapt the technology for use in improving hygiene and access to safe drinking water in developing communities by utilizing widely-available natural products as raw materials, and 3) facilitate development of a “greener,” more sustainable approach to chlorine generation.
Sunlight-driven photocatalytic synthesis of free chlorine:
Antibiotic
resistance genes (ARGs) – present within extracellular
DNA or within intracellular DNA in association with
antibiotic resistant bacterial (ARB) cells – have been
identified as widespread contaminants of treated
drinking waters and wastewaters. We are investigating
the effectiveness of common drinking water and
wastewater disinfectants (i.e., HOCl, NH2Cl, O3,
ClO2, and UV light) in
deactivating the biological activities of ARGs
associated with both extracellular and intracellular
ARB DNA. As disinfectant reactivities toward DNA and
other cell constituents vary widely, substantial
variation is anticipated in the efficacy with which
each disinfectant is able to penetrate to and
deactivate ARGs contained within the cytoplasm of a
given ARB cell, as depicted in the following Figure
(note that UV penetrates relatively uniformly to DNA
Figure.
Diffusion of HOCl, NH2Cl,
O3, and ClO2 into (a) a generic
vegetative prokaryotic cell, and (b) probable
variations in oxidant concentrations with increasing
diffusion distance into the cell, in accord with
oxidant reactivities toward constituents of the cell
wall and cytoplasm.
contained within the
cytoplasm). As a consequence, one can anticipate
substantial differences in the relative extent to
which intracellular DNA (and associated ARGs) would be
degraded during treatment with each disinfectant.
As a major focus of this research, we are utilizing culture-based bacterial DNA transformation assays and real-time quantitative PCR to quantify the kinetics of ARG deactivation (i.e., loss of transforming activity) and degradation (i.e., loss of measurable gene copies) in various strains of bacteria during disinfection. In addition, the kinetics of intracellular ARG deactivation by each disinfectant are being correlated with measured rates of ARB cell inactivation to evaluate the likelihood that intact, biologically-active ARGs may persist within the remaining ARB cell debris even after cell death, and to determine the feasibility of modeling their degradation and deactivation during various water and wastewater disinfection processes. As an extension of this work, we are also investigating the impacts of exposure to disinfectants commonly used in healthcare practice (e.g., benzalkonium chloride, povidone-iodine, hydrogen peroxide, chlorhexidine) on ARG integrity within clinically-relevant strains of antibiotic resistant pathogenic bacteria. The results of this work are anticipated to facilitate optimization of disinfection for minimizing the dissemination of intact ARGs within natural and engineered aquatic systems, as well as in healthcare settings.
Degradation and deactivation of bacterial antibiotic resistance genes during exposure to water and healthcare disinfectants:
